No. Meaning No. Meaning
1 K Ink Cartridge New 9 Y Ink Cartridge Set
2 K Ink Cartridge Refill 10 Y Ink Cartridge New
3 C Ink Cartridge Set 11 Y Ink Cartridge Refill
4 C Ink Cartridge New 12 Not Used
5 C Ink Cartridge Refill 13
6 M Ink Cartridge Set 14
7 M Ink Cartridge New 15
Input Check: Ink Cartridge Levels
5-804-016 INPUT CHK RES:Y Yellow Ink Cartridge
5-804-017 INPUT CHK RES:M Magenta Ink Cartridge
5-804-018 INPUT CHK RES:C Cyan Ink Cartridge
5-804-019 INPUT CHK RES:K Black Ink Cartridge
Use this SP to display the amount of ink that remains in each ink cartridge.
Units: %
Encoder Readings
5-804-020 INPUT CHK MENC Horizontal Encoder
Use this SP to display the current reading of the main scan encoder.
5-804-021 INPUT CHK SENC Vertical Encoder
Use this SP to display the current reading of the sub scan encoder.
Board Temperature Sensors
5-804-022 INPUT CHK DTEMP Drive Board Temperature Sensor
SP Mode Service Tables
49
