Common Procedures
Simple Removals
Duplex Unit
1. Push and hold the left and right release tabs [A] together to unlock the duplex unit [B].
2. Pull the duplex unit out of the machine.
Reinstallation
• The duplex unit must be installed in the machine at all times. The machine will not operate without
the duplex unit installed.
• The locks on either end of the duplex unit lock automatically when the unit is attached to the back
of the printer.
4. Replacement and Adjustment
48
