Motors
Horizontal Motor
Preparation
• Duplex unit ( p.48)
• Top cover ( p.51 "Rear Cover, Top Cover")
• Canopy cover ( p.57)
• Rear cover ( p.51 "Rear Cover, Top Cover")
• Left cover ( p.56)
• Right cover ( p.54)
• Vertical encoder wheel ( p.71)
• Fan, Fan bracket ( p.91 "Fan")
• Unlock carriage unit ( p.64 "Unlocking, Moving the Carriage")
1. Push the carriage to the center.
4. Replacement and Adjustment
86
