Transport Belt
Transport Belt, Charge Roller, Pressure Plate, Pressure Rollers
Preparation
• Duplex unit ( p.48)
• Rear cover ( p.51 "Rear Cover, Top Cover")
• Top cover ( p.51 "Rear Cover, Top Cover")
• Canopy cover ( p.57)
• Right cover ( p.54)
• Left cover ( p.56)
• Front cover ( p.57 "Front Cover, Operation Panel Board")
• 2nd registration sensor ( p.107)
• Bypass drawer connector ( p.117)
• Vertical encoder wheel ( p.71)
• Carriage unit ( p.129)
1. Open the charge roller cover ( x 2).
