Ricoh BRG-P1w User Manual

• 100V : For NA
• 200V : For EU, Aaia
HVPS
Preparation
• Duplex unit ( p.48)
• Canopy cover ( p.57)
• Top cover ( p.51 "Rear Cover, Top Cover")
• Rear Cover ( p.51)
• Left Cover ( p.56)
• Feed clutch ( p.93)
• Vertical motor ( p.88)
• Vertical encoder wheel ( p.71)
1. Turn the HVPS over together with its cover( x 2, x 5).
Boards
79
