• E-24B User Software DVD
•
USB Setup Tool program Ver. 2.0.25 or later
• USB 3.0 or 2.0 flash drive, at least 16 GB capacity (Max. 32GB)
• It is recommended to prepare a USB 3.0 flash drive for this model when installing the system
from a USB flash drive. The system software size of the E-24B has been increased from
previous Fiery embedded type controllers.
Time required for installation (file transfer phase):
USB 3.0 USB2.0
E-24B (This model) About 10 minutes About 20 minutes
E-22B (Previous model) Not supported About 10 minutes
• Note: If a USB 3.0 flash drive is unintentionally attached to the USB 2.0 port, the time
required will be the same as for a USB 2.0 flash drive.
•
Windows 7/8/10 computer ("PC") with:
• DVD drive, built-in or attached
A DVD drive is not required if image files (*.ISO) of the system software and user software are
provided.
• Minimum 500MB of available memory.
If preparing from the image files (*.ISO), an additional 8GB memory is required (internal or
external disk)
• USB port (support for USB 2.0 or later is recommended)
• USB1.x can also be used, but it will take more time to copy the system software.
Installation Procedure
1. Install the USB Setup Tool application on the PC, if is not already installed.
1.
Download the USB Setup Tool from the firmware download site and extract it.
2. Double-click the Fiery_USBSetupTool.exe to start the installer.
3. When the setup wizard is launched, click Next.
4. Accept the terms of the license agreement and then click Next.
Wait while the installer verifies the installation requirements.
System Software Installation Procedure
111
