11: Machine: Image Position
1102: Auto Adjust Image Position
Number of Check Sheets
Set the number of check sheets to be printed when Auto Adjust Image Position is executed.
Setting Item Max. Value Min. Value Step Unit
01: 1 Sided/02: 2 Sided 100 1 1 None
Adjust Image Length According to Adjustment Result: Side 1/Side 2
Adjusts for the deviations in image length in the paper feed direction that occurs as a result of the
automatic image position adjustment. The adjustment results are applied on both the front and back
sides.
Setting Item Max. Value Min. Value Step Unit
03: With Feed 5 -5 0.01 mm
1103: Image Position Feedback Correction
When you use Image Position Feedback Correction, execute [Auto Adjust Image Position] in advance.
Correction Mode
Select the mode for Image Position Feedback Correction. When [No Detection Mark] is specified, the
image position is corrected based on the shape of the paper. When [Detection Mark] is specified, the
detection marks are printed in the corners, and the image position is corrected based on those marks
and the shape of the paper. Specify [Correction Off] when no adjustment is needed.
Setting Item Values
01: Setting Correction Off
No Detection Mark
Detection Mark
11: Machine: Image Position
159
