2. Take out the tab fence from the pocket on the right-hand side of the wide LCT.
3. Adjust the side fences according to the size of the tab stock to be loaded, and then load
the tab stock.
Load the tab stocks with their side with the tabs facing the end fence.
4. Attach the tab fence, and then align the end fence gently against the paper you loaded
while pressing the release button of the end fence.
5. Carefully push the paper tray fully in until it clicks.
• Replace the tab fence after use.
Attaching the Small Tab End Fence to the Wide Large Capacity Tray
When loading carbonless paper of paper weight 2 or less, attach the small tab end fence.
1. Check that paper in the paper tray is not being used, and then pull the tray carefully out
until it stops.
2. Paper Specifications and Adding Paper
86
