0518: Counter Setting for Operating Multiple Fuser Units
Specify the behavior of the counters on the cleaning unit and fusing belt smoothing roller when
exchanging one fusing unit for another
When [Coordinate (Switch Counter Value )] is selected, the counters on the cleaning unit and fusing belt
smoothing roller change after replacing the fusing unit.
When [Not Coordinate (Carry-Over Counter Value )] is selected, the counter values of the cleaning unit
and fusing belt smoothing roller are carried over after replacing the fusing unit.
Setting Item Setting Value Default
01: Cleaning Unit
02: Fusing Belt Smoothing Roller
Coordinate (Switch
Counter Value )
Not Coordinate (Carry-
Over Counter Value )
Not Coordinate
(Carry-Over Counter
Value )
0594: ITB: Reset Belt Position at Replacement
Resets the operating conditions of the Intermediate Transfer Belt according to the belt position.
Execute this after you replace the Intermediate Transfer Belt.
Setting Item Description
01: Execute Press [Execute] to execute the function.
0595: ITB: Feedback Sensor Light Intensity Adjustment
Resets the operating conditions of the Intermediate Transfer Belt according to the light intensity.
Execute this after you clean the feedback sensor or replace the Intermediate Transfer Belt.
Setting Item Description
01: Execute Press [Execute] to execute the function.
0596: ITB: Feedback Sensor Initial Phase Acquisition
Resets the operating conditions of the Intermediate Transfer Belt according to the phase.
Execute this after you replace the Intermediate Transfer Belt and execute [ITB: Feedback Sensor Light
Intensity Adjustment].
5. Adjustment Settings for Operators
210
