0638: Accuracy Priority for Stapling
Set the accuracy priority for stapling.
This function can be used with Finisher or Booklet Finisher.
Setting Item
Values
Default Value
01: Setting
Speed Priority
Accuracy Priority
Speed Priority
0639: Accuracy Priority for Booklet
Set the accuracy priority for a booklet.
This function can be used with Booklet Finisher.
Setting Item
Values
Default Value
01: Setting
Speed Priority
Accuracy Priority
Speed Priority
