Roland VS-2400CD User Manual

33—VGA Main Display Mixer Views
430 www.RolandUS.com Roland VS-2400CD Owner’s Manual
6. AUX Send Sliders
7. DIR (DIRECT) 1-8 Selector
8. MUTE (M) Button
9. SOLO (S) Button
10. AUTOMIX STATUS (A) Button
11. GRP (GROUP) Selector
12. PAN Knob
13. Channel Fader
Set the amount of the channel’s signal sent to an Aux bus by adjusting
the corresponding AUX send slider. With linked Aux busses, a panning
handle replaces the even-numbered Aux bus’s slider (Page 425).
To route the channel’s signal to a Direct path, click the desired bus’s
number.
To mute the channel, click this button so it’s lit. To un-mute the channel,
click the button again.
To solo the channel, click the SOLO button to light it. To un-solo the
channel, click the button again.
When Automix is turned on, repeatedly click the AUTOMIX STATUS
button to set the channel’s Automix status.
To assign the channel to a fader group, click beneath “GRP” and
select the desired fader group from the pop-up menu.
Set the stereo position of the channel in the main MASTER bus mix by
dragging the PAN knob up or down as desired.
The position of the fader sets the level of signal coming out of the
channel. Moving the onscreen fader is the same as moving the
channel’s physical fader on the VS-2400CD.
148
151
138
138
318
150
152
150
