5
ShopTurn Functions 08/2005
5.2 Drillin
5
♥ Siemens AG, 2005. All rights reserved
5-182 SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition
5.2.9 Line position pattern
The "Line position pattern" function is used to program any number of
positions that lie equidistant on a line.
Positions >
¾ Press the "Drilling", "Positions" and "Line/Matrix/Box" soft keys.
¾ Select the “Line” position pattern in the "Line/Matrix/Box”
parameter field.
Parameters Description Unit
Position Select from 8 different positions:
End face/End face C – Front
End face/End face C – Rear
Peripheral surface/Peripheral surface C – Inner
Peripheral surface/Peripheral surface C – Outer
End face Y – Front (only when Y axis exists)
End face Y – Rear (only when Y axis exists)
Peripheral surface Y – inner (only when Y axis exists)
Peripheral surface Y – Rear (only when Y axis exists)
Z0
X0
Y0
α0
End face/End face C:
Z coordinate of the reference point (abs.)
X coordinate of the reference point – first position (abs.)
Y coordinate of the reference point – first position (abs.)
Angle of rotation of line in relation to the X axis
Positive angle: Line is rotated counterclockwise.
Negative angle: Line is rotated clockwise.
mm
mm
mm
Degrees
X0
Y0
Z0
α0
Peripheral surface/Peripheral surface C:
Cylinder diameter ¬ (abs.)
Y coordinate of the reference point – first position (abs.)
Z coordinate of the reference point – first position (abs.)
Angle of rotation of line with reference to Y axis
Positive angle: Line is rotated counterclockwise.
Negative angle: Line is rotated clockwise.
mm
mm
mm
Degrees
Z0
CP
X0
Y0
α0
End face Y:
Z coordinate of the reference point (abs.)
Positioning angle for machining area
X coordinate of the reference point – first position (abs.)
Y coordinate of the reference point – first position (abs.)
Angle of rotation of line in relation to the X axis
Positive angle: Line is rotated counterclockwise.
Negative angle: Line is rotated clockwise.
mm
Degrees
mm
mm
Degrees
