5
08/2005 ShopTurn Functions
5.4 Contour turnin
g
5
♥ Siemens AG, 2005. All rights reserved
SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition 5-233
5.4.10 Plunge-turning residual material
The "Plunge-turning residual material" function is used when you want
to machine the material that remained after grooving along the
contour.
During plunge-turning, ShopTurn automatically detects any residual
material and generates an updated blank contour. Material that
remains as part of the finishing allowance is not residual material. The
"Plunge-turning residual material" function allows you to remove
unwanted material with a suitable tool.
The "Plunge-turning residual material" function is a software option.
Plunge-turn
resid.
¾ Press the "Contour turning" and "Plunge-turn. resid." soft keys.
Parameters Description Unit
T, D, S, V See Sec. "Creating program blocks".
FX Feed in X direction mm/rev
FZ Feed in Z direction mm/rev
Machining
type
Roughing
Finishing
Stock removal
direction
Stock removal direction: Longitudinal or transverse
Machining side Machining side:
For stock removal in longitudinal direction: External or internal
For stock removal in transverse direction: end face or rear side
D Infeed depth for roughing (inc.) mm
XDA 1. grooving limit tool (inc) – (end face or rear face only) mm
XDB 2. grooving limit tool (inc) – (end face or rear face only) mm
U Finishing allowance in X and Z direction (inc) – (roughing only) – (alternative to UX
and UZ)
mm
UX Finishing allowance in X direction (inc) – (roughing only) – (alternative to U) mm
UZ Finishing allowance in Z direction (inc) – (roughing only) – (alternative to U) mm
Stock
allowance
Compensation allowance for contour or not – (finishing only)
