3
Machining the Workpiece 08/2005
3.3 Dis
la
in
the current
ro
ram block
3
♥ Siemens AG, 2005. All rights reserved
3-94 SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition
Single block fine
Load a program in "Machine Auto" mode (see Sec.
"Starting/stopping machining").
Single
Block Fine
Press the softkeys "Prog. Cntrl“ and "Single Block Fine," in order
to execute each individual drilling position and each individual
pocket milling movement as its own block.
Single Block
Press the "Single Block" key.
Continue as described under "Single Block".
3.3 Displaying the current program block
If you want precise information about axis positions and key G
functions during a trial run or execution of the program, you can show
the basic block display.
You can use the basic block display both in test mode and when
machining the workpiece on the machine. All G code commands that
initiate a function on the machine are displayed in the "Basic block"
window for the currently active program block:
Absolute axis positions
G functions for the first G group
Other modal G functions
Other programmed addresses
M functions
The basic block display function must be set up by the machine
manufacturer.
Please also refer to the machine manufacturer's instructions.
Load a program in "Machine Auto" mode (see Sec.
"Starting/stopping machining").
Basic Block
Press the "Basic Block" softkey.
Single Block
Press the "Single Block" key if you wish to execute the program
block by block.
Cycle Start
Start program execution.
The precise axis positions, modal G functions, etc., are displayed in
the "Basic block" window for the currently active program block.
