6
08/2005 Working with Manual Machine
6.4 More com
lex machinin
in manual mode
6
♥ Siemens AG, 2005. All rights reserved
SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition 6-339
6.4 More complex machining in manual mode
The following functions are available to you for comprehensive
machining in manual mode:
Drilling (axial drilling, axial threads, drilling, reaming, deep-drilling,
threads)
Turning (stock removal, groove, undercut, threads, tapping)
Milling (pocket, shank, groove, multi-edged, engraving)
General machining
sequence
For more complex machining processes, proceed in the following
order:
1. Select the desired function via the corresponding softkey.
Input the desired values in the parameter screen form.
2. Press the "OK" softkey in order to accept the values.
The input screen form closes.
A line with the specified parameters is displayed on the basic
screen.
3. Press the "Cycle Start" key.
The selected cycle is started.
You can return to the parameter screen form at any time to check and
correct the inputs.
Press the "Cursor right" key to jump back to the input screen form.
Approaching and
returning
When machining the workpiece, you traverse from the current position
to the machining start point. After the machining process, the tool is
returned along a direct path to the starting point.
