8
08/2005 Tool Management
8.6 Relocatin
a tool
8
♥ Siemens AG, 2005. All rights reserved
SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition 8-367
Unloading all tools from
the magazine
îš¾ Select the "Magazine" softkey in the "Tools WOs" operating area.
Unload
all
Unload
îš¾ Press the "Unload all" and "Unload" softkeys.
All tools are unloaded from the magazine.
Abort
You can abort the unloading process at any time by pressing the
"Abort" soft key. The current tool is unloaded and then the process is
aborted.
The unloading process is also aborted if you exit the magazine list.
8.6 Relocating a tool
Tools can be relocated within magazines or between different
magazines, which means that you do not have to unload tools from
the magazine in order to load them into a different location.
ShopTurn automatically suggests an empty location to which you can
relocate the tool. The magazine in which ShopTurn searches for an
empty location first is stored in a machine data code.
Please also refer to the machine manufacturer's instructions.
You can also specify an empty magazine location directly or define the
magazine ShopTurn should search for an empty location.
If your machine has just one magazine, you only need to enter the
location number you require, not the magazine number.
If a spindle location is shown in the tool list, you can also attach or
detach a tool directly to or from the spindle.
Please also refer to the machine manufacturer's instructions.
