1.3 Operator interface
1.3.1 Overview
Screen layout
User interface
1 Active operating mode/operating area and secondary mode
2 Alarm and message line
3 Program name
4 Program path
5 Channel state and program control
6 Channel operational messages
7 Position display of the axes
8 Display for
active tool T
current feedrate F
active spindle (S1 = main spindle, S2 = tool spindle,
S3 = counter spindle)
spindle utilization in percent
9 Display of active work offsets and rotation
10 Working window
11 Dialog line for additional explanatory text
12 Horizontal softkey bar
13 Vertical softkey bar
14 Softkeys
15 Screen buttons
