9
Program Management 08/2005
9.2 Mana
in
ro
rams with Sho
Turn on NCU
HMI Embedded
9
♥ Siemens AG, 2005. All rights reserved
9-384 SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition
9.2.8 Saving/reading-in tool/zero-point data
Apart from programs, you can also save tool data and zero point
settings.
You can use this function, for example, to save the tool and zero point
data for a specific sequential control program. If you want to execute
this program at a later point in time, you will then have quick access to
the relevant settings.
Even tool data that you have measured on an external tool setting
station can be copied easily into the tool management system using
this option. For further details, see:
References: /FBT/, Commissioning Manual CNC Part 4
(ShopTurn), SINUMERIK 840D sl/840 DE sl
You can choose which data you want to back up:
Tool data
Magazine loading
Zero points
Basic zero point
You can also specify the amount of data to be backed up:
Complete tool list or all zero points
All tool data or zero points used in the program
The read-out of the magazine usage is only possible if your system
provides for loading/unloading of tool data into/out of the magazine
(see Sec. "Tool management", section "Loading/unloading a tool into
the magazine").
Saving data
Open the Program Manager.
Place the cursor on the program whose tool and zero point data
you wish to back up.
Continue
>
Back up
data
Select the "Continue" and "Back up data" softkeys.
Select the data you want to back up.
Change the suggested name if you want to.
The name of the originally selected program with extension
"..._TMZ" will be suggested as a name for your tool or zero point
file.
