Suzuki RM-Z250 Service Manual

18-2 FRONT FORK AND STEERING
CONSTRUCTION
FRONT FORK
FWD
1 O-ring A Inner tube 
2 Slide bushing B Fork protector ITEM N·m kgf-m lbf-ft
3 Outer tube A Air bleeder valve A 1.3 0.13 1.0
4 Push rod B Compression damper unit B 30 3.0 21.5
5 Fork spring C Fork cap bolt C 34 3.4 24.5
6 Guide busing D Lock-nut/Center bolt D 22 2.2 16.0
7 Seal retainer E Front axle holder bolt E 18 1.8 13.0
8 Oil seal F Center bolt F 69 6.9 50.0
9 Stopper ring G Fork protector bolt G 4.9 0.49 3.5
0 Dust seal
