PERIODIC MAINTENANCE 2-39
CHASSIS BOLTS AND NUTS
Check that all chassis bolts and nuts are tightened to their specified torque. (Refer to page 2-40 for the loca-
tions of the following nuts and bolts on the motorcycle.)
ITEM N·m kgf-m lbf-ft
1 Steering stem head nut 100 10.0 72.5
2 Handlebar clamp bolt 25 2.5 18.0
3 Handlebar holder set nut 44 4.4 32.0
4 Front fork upper clamp bolt 23 2.3 16.5
5 Front fork lower clamp bolt 23 2.3 16.5
6 Front fork cap bolt 34 3.4 24.5
7 Front axle bolt 35 3.5 25.5
8 Front axle holder bolt 18 1.8 13.0
9 Front brake master cylinder holder bolt
(Upper
)101.07.0
0 Front brake master cylinder holder bolt
(Lower
)121.28.5
A Front brake caliper mounting bolt 26 2.6 19.0
B Front brake pad mounting pin 18 1.8 13.0
C Brake hose union bolt (Front & Rear) 23 2.3 16.5
D Air bleeder valve (Front & Rear brake caliper) 6 0.6 4.5
E Brake disc bolt (Front) 11 1.1 8.0
F Brake disc bolt (Rear) 26 2.6 19.0
G Rear brake pad mounting pin 18 1.8 13.0
H Rear brake master cylinder mounting bolt 10 1.0 7.0
I Rear brake master cylinder rod lock-nut 6 0.6 4.5
J Footrest mounting bolt 35 3.5 25.5
K Rear brake pedal pivot bolt 29 2.9 21.0
L Swingarm pivot nut 70 7.0 50.5
M
Rear shock absorber mounting bolt/nut (Upper & Lower)
50 5.0 36.0
N Cushion rod bolt/nut (Front & Rear) 80 8.0 58.0
O Cushion lever bolt/nut 80 8.0 58.0
P Rear axle nut 90 9.0 65.0
Q Rear sprocket nut 30 3.0 21.5
R Seat rail bolt/nut 23 2.3 16.5
S Chain roller bolt/nut 23 2.3 16.5
T Spoke nipple 6 0.6 4.5
