3.8.25 Permitted driving inclinations
To ensure sufficient lubrication for the transmission and engine, it is essential to
follow the maximum driving angles when driving the tractor on a slope.
WARNING: Angles for safe driving should be smaller than stated to
avoid the tractor from tipping over.
Up and down slope with either front or rear end up 30°
Sideways with slope to right or left 35°
Combined slope angles; left or right / up or down
slope
25°/20°
Down slope to right or left 35°
Combined slope angles; right / up slope 30°/25°
Combined slope angles; right / down slope 30°/20°
Combined slope angles; left / up slope 30°/20°
Combined slope angles; left / down slope 25°/20°
3.9 Displays
The tractor is equipped with the tractor terminal display on the armrest, Proline
instrument panel display on the dashboard and the pillar display on the A-pillar
and, if the tractor includes the TwinTrac reverse drive system (optional), on the
C-pillar display.The C-pillar display shows the same information as the A-pillar
display.
The displays give information on the power shuttle, driving speed, fuel
consumption and so on. You can view and edit different values and setting
parameters via the displays.
3.9.1 Adjusting display brightness
The brightness of the Proline instrument panel display and the A-pillar display is
adjusted with the dimmer. In addition, the dimmer adjusts the brightness of the
lights in the light panel, air condition panel, the whole Proline instrument panel
and all the switches and buttons that have a light.
3. Operation
- 134 -
