3.12.16 Changing parameters
3.12.16.1 Setting the implement width
You can enter the editing counters view through the split drive view or through
the menu 3.
1. Enter the editing counter view.
• To enter the editing counter view from the split drive view, press the OK
button until the view is changed.
OR
• Press ESC.
• Navigate to the menu 3 with the up and down arrow buttons.
• Press the right arrow button in the menu 3 to enter the editing counters
view.
000
000
000
000
440
cm
01:32
13,2
3,7
137,7
h
km
ha
l
000
000
000
000
440
cm
01:32
13.2
3.70
137
h
km
ha
l
000
1
GUID-0EC4B14A-711E-4BEC-9A50-71E3C9E40C6B
1. Implement width
2. Press OK or the selector for the predefined factory/user settings.
The digit to be edited is underlined.
3. Select the digit to be edited with the right and left arrow buttons.
4. Change the digit value with the up or down arrow buttons or by rotating the
selector for the predefined factory/user settings.
5. Press the OK button or the selector for the predefined factory/user settings to
return to the editing counter view main level.
With a short press of the ESC button you can return to the menu 3. A long press
of the ESC button returns to the previously active drive display.
3. Operation
- 178 -
