5. Direct the spray against the air streaming direction.
6. Close the protection plate.
Tighten the knurled-head screw.
7. Lower the air conditioning cooler to the lower position.
Tighten the two fastening screws.
8. Close the engine cover.
4.7.2.4 Checking the oil level in the transmission system
Check the oil level in the transmission system periodically.
Steering and transmission share the same oil system.
GUID-71E25714-1694-4CDA-91F3-ED2400A225E6
1. Transmission oil filling plug
2. Transmission oil level gauge
1. Stop the engine and let it stand for a few minutes.
2. Check the oil level from the oil level gauge.
The oil level must be between minimum and maximum lines.
3. Add oil if necessary.
4.7.2.5 Checking the oil level in the hydraulic system
Check the oil level in the hydraulic system periodically.
1. Raise the front linkage and lower the front loader and rear linkage.
Maximum amount of oil returns to the hydraulic oil reservoir.
2. Stop the engine and let it stand for a few minutes.
4. Maintenance
- 315 -
