The different views are shown on the display in either two or three rows,
depending on the setting view.
• The bottom row view is fixed.
• Some of the views show the data in two rows and some in three.
3.10.1 Fixed views
Fixed views show the operating hours and the time.
Fixed views have two functions displayed on the bottom row, the operating hours
and the clock .
GUID-738D2BEA-C566-47B8-A363-17DD906C21B7
1. Operating hours
2. Clock
Operating hours
Operating hours are displayed in accuracy of one decimal place when the power
is on.
Clock
The clock is displayed on the bottom row, either in 12-hour or 24-hour mode.
You can change the time if it is not correct.
3.10.2 Single-row and two-row views
The Proline instrument panel display functions are seen in the middle of the view
in the size of two rows or on the top and middle row, depending on the function.
Different functions can be displayed at the same time on both rows.
When the power is turned on, the view that was selected last appears on the
display.
The following functions can be displayed on the display:
Symbol
Function
Working time (h:mm)
Cruise control
km/h/mph Driving speed (km/h/mph)
Wheel slip (%, 0-100)
Table continued on next page
3. Operation
- 136 -
