Valtra T series Versu User Manual

3.15.1.4 Controlling the auxiliary hydraulics rear valves 1 and 2 and front
valves 1F and 2F
You can control rear valves 1 and 2 or front valves 1F and 2F (optional) with the
joystick.
1
AUTO
CONTROL
2
OFF
1
2
GUID-9EF75916-AF70-408C-BC1B-70113729EE92
1. Joystick movement to control rear valve 1 and front valve 1F
2. Joystick movement to control rear valve 2 and front valve 2F
Use the joystick functions selector to choose the valves.
2
Position 1 1F 1 1F
Position 2 2F 2 2
WARNING:
Do not unnecessarily activate the programmed position locks for the
valves that are used by the joystick. There is a risk of engaging the
position lock.
IMPORTANT:
Do not turn the joystick around its vertical axis, because the joystick may become
damaged and the wires can break.
1. To use the lifting function (+), pull the joystick backward or left.
2. To use the lowering function (-), push the joystick forward or right.
3. To use the position lock or the floating position:
• Activate the position lock or the floating position from the tractor terminal.
• Set the valve to the position lock or the floating position by briefly (less
than one second) pushing the joystick into the extreme forward or right
position.
Pushing the joystick continuously forward/right keeps the floating position
activated until you release the joystick.
• To deactivate the position lock or the floating position, push the joystick
slightly forward/backward or right/left.
3. Operation
- 213 -
