6.4.3 Tyre loadings and pressures
NOTE: The permissible wheel load can reduce the maximum permissible axle
load.
Maximum permissible front axle load
At maximum permissible driving speed, road 5500 kg
In working conditions, offroad 8500 kg
IMPORTANT: On 50 km/h models and when driving at the maximum speed, the
tyre loading is smaller. For more information, see the tyre manufacturer's
catalogue.
6.5 Flange distance for axles
Front, industrial front axle (mm) 1 900 mm
Rear (mm) 1 754 mm
Max rear tyre diameter (mm) 1 999 mm
Min rear rim diameter (inches) 38”
Max front tyre diameter (mm) 1 522 mm
Min front rim diameter (inches) 28”
Distance between rear mudguards (mm) 960 mm
GUID-1835335E-C423-4BCA-B442-6E5A31AD7AD9
1. Distance between the top of the tyre and the mudguard, 60 mm
2. Distance between the side of the tyre and the mudguard, 40 mm
3. Mudguard
4. Narrowest track
6. Technical specifications
- 421 -
