GUID-3FFADF59-E7E3-4CA9-8926-1F930BCED527
1. 229 mm
2. T measure
6.9.5.5 Proportional ground speed power take-off
Model Power take-off (PTO) axle revolutions per one rear
wheel revolution
40 km/h 41.03
50 km/h 40.79
6.9.6 Front power take-off
Oil type
Oil volume (litres)
Shell Donax TX 2.8
Maximum input torque 1170 Nm
Nominal input torque 925 Nm
6.9.6.1 Front power take-off ratios
Front power take-off (PTO) ratio
1 000 rpm at engine speed 1 900 rpm
6.9.6.2 Front power take-off shafts
Splines
Standard Shaft diameter (mm)
6 ISO 500 35
6.10 Brake system
Operation
• Hydraulically controlled multi-disc type brakes
with wet discs
• Boosted with low-pressure hydraulics
• Two brake cylinders
• No separate brake fluid
• Pressure accumulator to ensure the pressure
• Oil spray cooling of the friction disc elements
when necessary
Number of brake friction discs 5 pcs/side
Friction disc diameter 242.5 mm
Brake friction area
4 272 cm
2
/org.
Brake pedal free travel 35-45 mm
6. Technical specifications
- 429 -
