• Start the rear PTO by pressing the switch down and pulling it backward.
The indicator light on the proline instrument panel is lit.
GUID-15597209-5561-4EBD-BA5E-A13223789DB0
1. Switch for rear PTO
• To start the rear PTO with the rear PTO on/off push button on the mudguard,
press the button continuously for at least 3 seconds.
The PTO starting begins after 0.5 seconds. If the pressing is interrupted
during these 3 seconds, the PTO stops.
GUID-CAAA1849-6895-4A59-BBC2-84694B1B18D4
1. Rear PTO on/off push button
3.18.2.4 Stopping rear power take-off temporarily
You can stop the rear power take-off (PTO) temporarily in the following ways:
3. Operation
- 239 -
