Front linkage
The front linkage is optional.
1
AUTO
CONTROL
2
OFF
ON
OFF
1
2
1
2
3
4
GUID-3EB09E37-93DA-499A-8371-FFEF86F4B088
1.
Auxiliary hydraulics on/off push button
2.
Joystick function selector
3.
Changeover button for front linkage / front loader (optional)
4.
Joystick
2. Instruments and controls
- 38 -
38
40
