4. Press OK or the selector for the predefined factory/user settings to activate
the valve point to be set.
The selected valve point starts to flash.
% %
-
+
100 1002
1 50 50
100 1004
100 100F1
100 1003
GUID-19AE50F4-02AB-491E-8EF1-97C1AA80D304
1. Selected valve point
5. Set the value and the function with the up and down arrow buttons or by
rotating the selector for the predefined factory/user settings.
The port flow can be set between 1–100%.
By pressing an arrow button or by rotating the selector for the predefined
factory/user settings, the functions appear successively:
• Position lock time 1–60 seconds
• Position lock
• Floating (not in + port)
• No function active = empty
NOTE:
For safety reasons the position locks of valves 1F and 2F cannot be activated
in front loader use. If the tractor is equipped with a change-over switch for
front linkage/front loader, the position lock settings of the related valves are
deactivated when you turn the change-over switch to the front loader
position.
6. The value is automatically saved when you deactivate the selected field by
moving the navigation box to another parameter or by pressing the ESC
button.
With a short press of the ESC button you can return to the menu 1.
A long press of the ESC button returns to the previously active drive display.
3.15.2.1 Auxiliary hydraulic control's safety time out
The auxiliary hydraulic control's safety time out is a safety function that prevents
unintentional movement of implements connected to the auxiliary hydraulics.
The auxiliary hydraulic control's safety time out deactivates the joystick after 1 km
of driving if the driving speed stays over the adjustable limit and the joystick has
not been used. You can adjust the speed limit between 5 and 65 km/h in steps of
5 km/h. Setting the speed limit to 65 km/h disables the auxiliary hydraulic
control's safety time out. The default setting is 20 km/h.
CAUTION:
3. Operation
- 218 -
