Valtra T series Versu User Manual

Symbol Function
l/h
Avg
l/h
Immediate fuel consumption
Average fuel consumption
Fuel consumption
Lower link position (%, 0-100)
Gearbox temperature (C/F)
Travel distance (m/km/miles)
Square area (ha)
RESET Counters reset
2.5.2 Indicator lights on the left side of the display
5
20
30
40
50
0
5
0
20
25
30
GUID-CB29C874-ACE0-4926-913A-C3F8F4E1CE27
Indicator light
Indication
GUID-3B4DA5EC-8F5A-4A6B-9F05-00
3A821F23D1
Turn signal indicator light of a vehicle combination with two trailers. The signal light
blinks when there are two trailers connected to the tractor, or one trailer with double
lamps. If a bulb of the trailer combination has failed the light is not lit.
When the hazard lights are switched on the signal light blinks if there are four turn
signals blinking in the trailer combination.
If the turn signal indicator light is lit during the first two blinks, there is a fault in the
direction indicator relay and it must be calibrated. Contact an authorised Valtra
workshop.
GUID-2A79A904-AD5A-4544-B5C3-
BB0100DB3265
Turn signal indicator light of a vehicle combination with one trailer having one pair of
lamps. The signal light blinks when there is one trailer connected to the tractor.
When the hazard lights are switched on the signal light blinks if there are two or three
turn signals blinking in the trailer.
If the turn signal indicator light is lit during the first two blinks, there is a fault in the
direction indicator relay and it must be calibrated. Contact an authorised Valtra
workshop.
GUID-1945DB50-4F62-415E-8EFA-3B
A4A422AE5C
Engine emission system failure or malfunction indicator light.
The light is lit when the AdBlue/DEF tank is empty or a malfunction occurs in the SCR-
system. If the AdBlue/DEF is not filled or the malfunction is on, after a period of time
the light begins to flash until the error is resolved. Engine torque and speed is reduced
to avoid excessive engine exhaust emissions.
GUID-670E595F-C714-4B9C-
B3E9-59F9EAEE02B4
Engine air cleaner clogging indicator light.
The light is lit when the engine is running and a buzzer sounds once to indicate that the
engine air filter is clogged and needs to be serviced.
GUID-
A94E67B5-80C5-471B-94AD-90062174
2615
Engine oil pressure light.
The light is lit when the engine is running, a buzzer sounds continuously and the STOP
indicator light flashes to indicate that the oil pressure is too low.
Table continued on next page
2. Instruments and controls
- 32 -
