3.18.2.5 Deactivating rear power take-off
WARNING: When you do not need the PTO, keep the PTO switch in
the N position.
WARNING: Use the PTO speed control knob for the actual
disengagement and engagement of the PTO. For example, when
leaving the cab, turn the knob to the N position, except when using the
PTO on/off push button on the mudguard (optional).
• Press down the rear PTO switch and push it forward.
GUID-15597209-5561-4EBD-BA5E-A13223789DB0
1. Switch for rear PTO
3. Operation
- 241 -
