3. Extract the support frame.
• Lower the support frame slightly.
• Pull the support frame outwards.
4. Remove the ventilation air filter.
5. Check the condition of the ventilation air filter.
A damaged ventilation air filter must be changed.
6. Clean the ventilation air filter.
• Knock the filter element against your palm so that most of the dirt comes
off.
• Use a vacuum cleaner to clean the ventilation air filter from the outside in
or blow it clean with compressed air from the center outwards.
IMPORTANT: Make sure that the air pressure is not too high.
4.8.9.2 Adjusting steps for driving off-road
1. On the right side, remove the lowest step completely by unscrewing two
screws.
GUID-B98FF92B-B587-49AF-933C-F6059087A9D4
1. Screws
4. Maintenance
- 406 -
