ABB ACS560 User Manual

Control macros 105
ABB standard macro (vector)
The ABB standard macro (vector) is similar to the ABB standard macro. The ABB
standard uses scalar motor control mode where as the ABB standard macro (vector)
uses vector control as motor control mode.
Similar to ABB standard macro, ABB standard (vector) has the following features:
• 2-wire I/O configuration with three constant frequency references
• Applicable for normal control purpose
• One signal is used to start or stop the motor and another signal is used to select
the direction.
To enable the macro, navigate to

• Main menu  Connection macro  ABB standard (vector)
or
• Main menu
 Complete parameter list parameter 96.04 Macro select 
[17] ABB standard (vector).

ABB ACS560 Specifications

General

Frequency	50/60 Hz
Control Method	Scalar control
Protection Features	Overcurrent, overvoltage, undervoltage, short circuit
Communication Interfaces	Modbus RTU, Profibus DP, CANopen, Ethernet/IP
Enclosure Rating	IP21
Ambient Temperature	-10 to +50 °C
Input Voltage	380 to 480 V AC
Cooling Method	Air cooling (natural convection or forced ventilation)
