258 Parameters
DI6 Digital input DI6 (10.02 DI delayed status, bit 5). 10
Other Source selection (see Terms and abbreviations on page 162). -
30.37 Min speed source Defines the source of a minimum speed limit for the drive
when the source is selected by 30.36 Speed limit selection.
WARNING! In vector motor control mode only. In
scalar motor control mode, use frequency limits 30.13
and 30.14.
Minimum
speed
Zero None. 0
AI1 scaled 12.12 AI1 scaled value.1
AI2 scaled 12.22 AI2 scaled value.2
Minimum speed 30.11 Minimum speed.11
Other Source selection (see Terms and abbreviations on page 162). -
30.38 Max speed source Minimum
speed
Zero None. 0
AI1 scaled 12.12 AI1 scaled value.1
AI2 scaled 12.22 AI2 scaled value.2
Maximum speed 30.12 Maximum speed.12
Other Source selection (see Terms and abbreviations on page 162). -
31
31 Fault functions
Configuration of external events; selection of behavior of the
drive upon fault situations.
31.01 External event 1
source
Defines the source of external event 1.
See also parameter 31.02 External event 1 type.
0 = Trigger event
1 = Normal operation
Inactive
(true)
Active (false) 0. 0
Inactive (true) 1. 1
DI1 Digital input DI1 (10.02 DI delayed status, bit 0). 3
DI2 Digital input DI2 (10.02 DI delayed status, bit 1). 4
DI3 Digital input DI3 (10.02 DI delayed status, bit 2). 5
DI4 Digital input DI4 (10.02 DI delayed status, bit 3). 6
DI5 Digital input DI5 (10.02 DI delayed status, bit 4). 7
DI6 Digital input DI6 (10.02 DI delayed status, bit 5). 8
Other [bit] Source selection (see Terms and abbreviations on page 162). -
31.02 External event 1
type
Selects the type of external event 1. Fault
Fault The external event generates a fault. 0
Warning The external event generates a warning. 1
31.03 External event 2
source
Defines the source of external event 2. See also parameter
31.04 External event 2 type.
For the selections, see parameter 31.01 External event 1
source.
Inactive
(true)
31.04 External event 2
type
Selects the type of external event 2. Fault
Fault The external event generates a fault. 0
No. Name/Value Description Def/FbEq16

ABB ACS560 Specifications

General

Frequency	50/60 Hz
Control Method	Scalar control
Protection Features	Overcurrent, overvoltage, undervoltage, short circuit
Communication Interfaces	Modbus RTU, Profibus DP, CANopen, Ethernet/IP
Enclosure Rating	IP21
Ambient Temperature	-10 to +50 °C
Input Voltage	380 to 480 V AC
Cooling Method	Air cooling (natural convection or forced ventilation)
