380 Additional parameter data
Parameter groups 10…99
No. Name Type Range Unit FbEq32
10 Standard DI, RO
10.01 DI status PB 0b0000...0b1111 - 1 = 1
10.02 DI delayed status PB 0b0000...0b1111 - 1 = 1
10.03 DI force selection PB 0b0000...0b1111 - 1 = 1
10.04 DI forced data PB 0b0000...0b1111 - 1 = 1
10.05 DI1 ON delay Real 0.00...3000.00 s 10 = 1
10.06 DI1 OFF delay Real 0.00...3000.00 s 10 = 1
10.07 DI2 ON delay Real 0.00...3000.00 s 10 = 1
10.08 DI2 OFF delay Real 0.00...3000.00 s 10 = 1
10.09 DI3 ON delay Real 0.00...3000.00 s 10 = 1
10.10 DI3 OFF delay Real 0.00...3000.00 s 10 = 1
10.11 DI4 ON delay Real 0.00...3000.00 s 10 = 1
10.12 DI4 OFF delay Real 0.00...3000.00 s 10 = 1
10.13 DI5 ON delay Real 0.00...3000.00 s 10 = 1
10.14 DI5 OFF delay Real 0.00...3000.00 s 10 = 1
10.15 DI6 ON delay Real 0.00...3000.00 s 10 = 1
10.16 DI6 OFF delay Real 0.00...3000.00 s 10 = 1
10.21 RO status PB 0b0000...0b1111 - 1 = 1
10.22 RO force selection PB 0b0000...0b1111 - 1 = 1
10.23 RO forced data PB 0b0000...0b1111 - 1 = 1
10.24 RO1 source Binary
src
--1 = 1
10.25 RO1 ON delay Real 0.0…3000.0 s 10 = 1 s
10.26 RO1 OFF delay Real 0.0…3000.0 s 10 = 1 s
10.27 RO2 source Binary
src
--1 = 1
10.28 RO2 ON delay Real 0.0…3000.0 s 10 = 1 s
10.29 RO2 OFF delay Real 0.0…3000.0 s 10 = 1 s
10.30 RO3 source Binary
src
--1 = 1
10.31 RO3 ON delay Real 0.0…3000.0 s 10 = 1 s
10.32 RO3 OFF delay Real 0.0…3000.0 s 10 = 1 s
10.99 RO/DIO control word PB 0b0000...0b1111 - 1 = 1
10.101 RO1 toggle counter Real
0…4294967000 - 1 = 1
10.102 RO2 toggle counter Real 0…4294967000 - 1 = 1
10.103 RO3 toggle counter Real 0…4294967000 - 1 = 1
11 Standard DIO, FI, FO
11.21 DI5 configuration List 0…1 - 1 = 1
11.38 Freq in 1 actual value Real 0…16000 Hz 1 = 1 Hz
11.39 Freq in 1 scaled value Real -32768.000…32767.000 - 1000 = 1
