ABB ACS560 User Manual

332 Parameters
Other Source selection (see Terms and abbreviations on page 162). -
…… … …
52.12 FBA A data in12 See parameter 52.01 FBA A data in1. None
53
53 FBA A data out
Selection of data to be transferred from fieldbus controller to
drive through fieldbus adapter A.
Note: 32-bit values require two consecutive parameters.
Whenever a 32-bit value is selected in a data parameter, the
next parameter is automatically reserved.
53.01 FBA A data out1 Parameters 53.01…53.12 select data to be transferred from
the fieldbus controller to the drive through fieldbus adapter A.
None
None None. 0
CW 16bit Control Word (16 bits) 1
Ref1 16bit Reference REF1 (16 bits) 2
Ref2 16bit Reference REF2 (16 bits) 3
CW 32bit Control Word (32 bits) 11
Ref1 32bit Reference REF1 (32 bits) 12
Ref2 32bit Reference REF2 (32 bits) 13
CW2 16bit Control Word 2 (16 bits) 21
Other Source selection (see Terms and abbreviations on page 162). -
…… … …
53.12 FBA A data out12 See parameter 53.01 FBA A data out1. None
58
58 Embedded fieldbus
Configuration of the embedded fieldbus (EFB) interface.
See also chapter Fieldbus control through the embedded
fieldbus interface (EFB) (page 437).
58.01 Protocol enable Enables/disables the embedded fieldbus interface and
selects the protocol to use.
None
None None (communication disabled). 0
Modbus RTU Embedded fieldbus interface is enabled and uses the Modbus
RTU protocol.
1
58.02 Protocol ID Displays the protocol ID and revision.
This parameter is read-only.
-
Protocol ID and revision. 1 = 1
58.03 Node address Defines the node address of the drive on the fieldbus link.
Values 1…247 are allowable. Two devices with the same
address are not allowed on-line.
Changes to this parameter take effect after the control unit is
rebooted or the new settings validated by parameter 58.06
Communication control (Refresh settings).
1
0…255 Node address (values 1…247 are allowed). 1 = 1
58.04 Baud rate Selects the transfer rate of the fieldbus link.
Changes to this parameter take effect after the control unit is
rebooted or the new settings validated by parameter 58.06
Communication control (Refresh settings).
19.2 kbps
Autodetect Baud rate detected automatically 0
4.8 kbps 4.8 kbit/s. 1
9.6 kbps 9.6 kbit/s. 2
No. Name/Value Description Def/FbEq16

ABB ACS560 Specifications

General

Frequency	50/60 Hz
Control Method	Scalar control
Protection Features	Overcurrent, overvoltage, undervoltage, short circuit
Communication Interfaces	Modbus RTU, Profibus DP, CANopen, Ethernet/IP
Enclosure Rating	IP21
Ambient Temperature	-10 to +50 °C
Input Voltage	380 to 480 V AC
Cooling Method	Air cooling (natural convection or forced ventilation)
