Fault tracing 409
8
Fault tracing
What this chapter contains
The chapter lists the warning and fault messages including possible causes and
corrective actions. The causes of most warnings and faults can be identified and
corrected using the information in this chapter. If not, contact an ABB service
representative. If you have a possibility to use the Drive composer PC tool, send the
Support package created by the Drive composer to the ABB service representative.
Warnings and faults are listed below in separate tables. Each table is sorted by
warning/fault code.
Safety
WARNING! Only qualified electricians are allowed to service the drive. Read
the instructions in chapter Safety instructions at the beginning of the Hardware
manual of the drive before working on the drive.
Indications
 Warnings and faults
Warnings and faults indicate an abnormal drive status. The codes of active warnings
and faults are displayed on the control panel of the drive as well as in the Drive
composer PC tool with warning and fault names. Only the codes of warnings and
faults are available over fieldbus.
Warnings do not need to be reset; they stop showing when the cause of the warning
ceases. Warnings do not latch and the drive will continue to operate the motor.

ABB ACS560 Specifications

General

Frequency	50/60 Hz
Control Method	Scalar control
Protection Features	Overcurrent, overvoltage, undervoltage, short circuit
Communication Interfaces	Modbus RTU, Profibus DP, CANopen, Ethernet/IP
Enclosure Rating	IP21
Ambient Temperature	-10 to +50 °C
Input Voltage	380 to 480 V AC
Cooling Method	Air cooling (natural convection or forced ventilation)
