ABB ACS560 User Manual

Parameters 165
Parameter listing
No. Name/Value Description Def/FbEq16
01
01 Actual values
Basic signals for monitoring the drive.
All parameters in this group are read-only unless otherwise
noted.
Note: Values of these actual signals are filtered with the filter
time defined in group 46 Monitoring/scaling settings. The
selection lists for parameters in other groups mean the raw
value of the actual signal instead. For example, if a selection
is “Output frequency” it does not point to the value of
parameter 01.06 Output frequency but to the raw value.
01.01 Motor speed used Estimated motor speed. A filter time constant for this signal
can be defined by parameter 46.11 Filter time motor speed.
-
-30000.00…
30000.00 rpm
Estimated motor speed. See par.
46.01
01.02 Motor speed
estimated
Estimated motor speed in rpm. A filter time constant for this
signal can be defined by parameter 46.11 Filter time motor
speed.
-
-30000.00…
30000.00 rpm
Estimated motor speed. See par.
46.01
01.03 Motor speed % Motor speed in percent of the synchronous motor speed. -
-1000.00…
1000.00%
Motor speed. 10 = 1%
01.06 Output frequency Estimated drive output frequency in Hz. A filter time constant
for this signal can be defined by parameter 46.12 Filter time
output frequency.
-
-500.00…500.00
Hz
Estimated output frequency. See par.
46.02
01.07 Motor current Measured (absolute) motor current in A. -
0.00…30000.00 A Motor current. 1 = 1 A
01.08 Motor current % of
motor nom
Motor current (drive output current) in percent of the nominal
motor current.
-
0.0…1000.0% Motor current. 1 = 1%
01.09 Motor current % of
drive nom
Motor current (drive output current) in percent of the nominal
drive current.
-
0.0…1000.0% Motor current. 1 = 1%
01.10 Motor torque Motor torque in percent of the nominal motor torque. See also
parameter 01.30 Nominal torque scale.
A filter time constant for this signal can be defined by
parameter 46.13 Filter time motor torque.
-
-1600.0…1600.0% Motor torque. See par.
46.03
01.11 DC voltage Measured DC link voltage. -
0.00…2000.00 V DC link voltage. 10 = 1 V
01.13 Output voltage Calculated motor voltage in V AC. -
0…2000 V Motor voltage. 1 = 1 V

ABB ACS560 Specifications

General

Frequency	50/60 Hz
Control Method	Scalar control
Protection Features	Overcurrent, overvoltage, undervoltage, short circuit
Communication Interfaces	Modbus RTU, Profibus DP, CANopen, Ethernet/IP
Enclosure Rating	IP21
Ambient Temperature	-10 to +50 °C
Input Voltage	380 to 480 V AC
Cooling Method	Air cooling (natural convection or forced ventilation)
