Parameters 209
DI1 Digital input DI1 (10.02 DI delayed status, bit 0) 2
DI2 Digital input DI2 (10.02 DI delayed status, bit 1) 3
DI3 Digital input DI3 (10.02 DI delayed status, bit 2) 4
DI4 Digital input DI4 (10.02 DI delayed status, bit 3) 5
DI5 Digital input DI5 (10.02 DI delayed status, bit 4) 6
DI6 Digital input DI6 (10.02 DI delayed status, bit 5) 7
Timed function 1 Bit 0 of 34.01 Timed functions status (see page 273)18
Timed function 2 Bit 1 of 34.01 Timed functions status (see page 273)19
Timed function 3 Bit 2 of 34.01 Timed functions status (see page 273)20
Supervision 1 Bit 0 of 32.01 Supervision status (see page 266)24
Supervision 2 Bit 1 of 32.01 Supervision status (see page 266)25
Supervision 3 Bit 2 of 32.01 Supervision status (see page 266)26
Other [bit] Source selection (see Terms and abbreviations on page 162)-
20.27 Jogging 2 start
source
If enabled by parameter 20.25 Jogging enable, selects the
source for the activation of jogging function 2. (Jogging
function 2 can also be activated through fieldbus regardless
of parameter 20.25.)
1 = Jogging 2 active.
For the selections, see parameter 20.26 Jogging 1 start
source.
Notes:
• If both jogging 1 and 2 are activated, the one that was
activated first has priority.
• This parameter cannot be changed while the drive is
running.
Not selected
21
21 Start/stop mode
Start and stop modes; emergency stop mode and signal
source selection; DC magnetization settings.
21.01 Start mode Selects the motor start function for the vector motor control
mode, ie. when 99.04 Motor control mode is set to Vector.
Notes:
• The start function for the scalar motor control mode is
selected by parameter 21.19 Scalar start mode.
• Starting into a rotating motor is not possible when DC
magnetizing is selected (Fast or Const time).
• This parameter cannot be changed while the drive is
running.
See also section DC magnetization (page 70).
Automatic
Fast The drive pre-magnetizes the motor before start. The pre-
magnetizing time is determined automatically, being typically
200 ms to 2 s depending on motor size. This mode should be
selected if a high break-away torque is required.
0
No. Name/Value Description Def/FbEq16
