ABB ACS560 User Manual

Parameters 169
03.10 EFB reference 2 Scaled reference 2 received through the embedded fieldbus
interface.
1 = 10
-30000.00…
30000.00
Scaled reference 2 received through the embedded fieldbus
interface.
1 = 10
04
04 Warnings and faults
Information on warnings and faults that occurred last.
For explanations of individual warning and fault codes, see
chapter Fault tracing.
All parameters in this group are read-only unless otherwise
noted.
04.01 Tripping fault Code of the 1st active fault (the fault that caused the current
trip).
0x0000
0x0000...0xffff 1st active fault. 1 = 1
04.02 Active fault 2 Code of the 2nd active fault. 0x0000
0x0000...0xffff 2nd active fault. 1 = 1
04.03 Active fault 3 Code of the 3rd active fault. 0x0000
0x0000...0xffff 3rd active fault. 1 = 1
04.06 Active warning 1 Code of the 1st active warning. 0x0000
0x0000...0xffff 1st active warning. 1 = 1
04.07 Active warning 2 Code of the 2nd active warning. 0x0000
0x0000...0xffff 2nd active warning. 1 = 1
04.08 Active warning 3 Code of the 3rd active warning. 0x0000
0x0000...0xffff 3rd active warning. 1 = 1
04.11 Latest fault Code of the 1st stored (non-active) fault. 0x0000
0x0000...0xffff 1st stored fault. 1 = 1
04.12 2nd latest fault Code of the 2nd stored (non-active) fault. 0x0000
0x0000...0xffff 2nd stored fault. 1 = 1
04.13 3rd latest fault Code of the 3rd stored (non-active) fault. 0x0000
0x0000...0xffff 3rd stored fault. 1 = 1
04.16 Latest warning Code of the 1st stored (non-active) warning. 0x0000
0x0000...0xffff 1st stored warning. 1 = 1
04.17 2nd latest warning Code of the 2nd stored (non-active) warning. 0x0000
0x0000...0xffff 2nd stored warning. 1 = 1
04.18 3rd latest warning Code of the 3rd stored (non-active) warning. 0x0000
0x0000...0xffff 3rd stored warning. 1 = 1
No. Name/Value Description Def/FbEq16

ABB ACS560 Specifications

General

Frequency	50/60 Hz
Control Method	Scalar control
Protection Features	Overcurrent, overvoltage, undervoltage, short circuit
Communication Interfaces	Modbus RTU, Profibus DP, CANopen, Ethernet/IP
Enclosure Rating	IP21
Ambient Temperature	-10 to +50 °C
Input Voltage	380 to 480 V AC
Cooling Method	Air cooling (natural convection or forced ventilation)
