ABB ACS560 User Manual

Parameters 351
76.83 PFC interlock 3 See parameter 76.82 PFC interlock 1. Available.
PFC motor is
available
76.84 PFC interlock 4 See parameter 76.82 PFC interlock 1. Available.
PFC motor is
available
76.95 Regulator bypass
control
Defines if direct-on-line pumps are automatically started and
stopped.
This setting can be used in applications with a low number of
sensors and low accuracy requirements.
Disable
Disable Automatic starting and stopping is disabled. 0
Enable Automatic starting and stopping is enabled. 1
Other [bit] Source selection (see Terms and abbreviations on page 162). -
77
77 PFC maintenance
and monitoring
PFC (Pump and fan control) maintenance and monitoring
parameters.
77.10 PFC runtime
change
Enables the reset, or arbitrary setting, of 77.11 Pump/fan 1
running time … 77.14 Pump/fan 4 running time.
Done
Done The parameter automatically reverts back to this value. 0
Set any PFC run
time
Enables the setting of 77.11 Pump/fan 1 running time …
77.14 Pump/fan 4 running time to an arbitrary value.
1
Reset PFC1 run
time
Resets parameter 77.11 Pump/fan 1 running time.2
Reset PFC2 run
time
Resets parameter 77.12 Pump/fan 2 running time.3
Reset PFC3 run
time
Resets parameter 77.13 Pump/fan 3 running time.4
Reset PFC4 run
time
Resets parameter 77.14 Pump/fan 4 running time.5
77.11 Pump/fan 1 running
time
Running time counter of pump/fan 1. Can be set or reset by
parameter 77.10 Pump/fan 1 running time.
0.00 h
0.00…42949672.95
h
Time 1 = 1 h
77.12 Pump/fan 2 running
time
See parameter 77.11 Pump/fan 1 running time.0.00h
77.13 Pump/fan 3 running
time
See parameter 77.11 Pump/fan 1 running time.0.00h
77.14 Pump/fan 4 running
time
See parameter 77.11 Pump/fan 1 running time.0.00h
No. Name/Value Description Def/FbEq16

ABB ACS560 Specifications

General

Frequency	50/60 Hz
Control Method	Scalar control
Protection Features	Overcurrent, overvoltage, undervoltage, short circuit
Communication Interfaces	Modbus RTU, Profibus DP, CANopen, Ethernet/IP
Enclosure Rating	IP21
Ambient Temperature	-10 to +50 °C
Input Voltage	380 to 480 V AC
Cooling Method	Air cooling (natural convection or forced ventilation)
