178 Parameters
06.32 MSW bit 13
selection
Selects a binary source whose status is transmitted as bit 13
(User bit 2) of 06.11 Main status word.
False
False 0 0
True 1 1
Other [bit] Source selection (see Terms and abbreviations on page 162)-
06.33 MSW bit 14
selection
Selects a binary source whose status is transmitted as bit 14
(User bit 3) of 06.11 Main status word.
False
False 0 0
True 1 1
Other [bit] Source selection (see Terms and abbreviations on page 162)-
07
07 System info
Drive hardware and firmware information.
All parameters in this group are read-only.
07.03 Drive rating id Type of the drive. (Rating ID in brackets.) Not selected
07.04 Firmware name Firmware identification. -
07.05 Firmware version Version number of the firmware. 0.00.0.0
0.00.0.0...255.255.
255.255
-1=1
07.06 Loading package
name
Name of the firmware loading package. -
07.07 Loading package
version
Version number of the firmware loading package. 0.00.0.0
0.00.0.0...255.255.
255.255
-1=1
07.11 Cpu usage Microprocessor load in percent. 0
0…100% Microprocessor load. 1 = 1
07.35 Drive configuration Plug ‘n’ play configuration. Drive automatically detects and
enables any installed fieldbus or C-series option.
0x0000
0x0000...0xffff Drive configuration. 1 = 1
No. Name/Value Description Def/FbEq16
Bit Name Bit Name
0 Reserved 8 BIO-01
1 Base unit 9 RIIO-01
2 Reserved 10 FSCA-01
3FENA-21 11 FEIP-21
4 FECA-01 12 FMBT-21
5 FPBA-01 13
6 FCAN-01 14 FPNO-21
7 Reserved 15 FEPL-02

ABB ACS560 Specifications

General

Frequency	50/60 Hz
Control Method	Scalar control
Protection Features	Overcurrent, overvoltage, undervoltage, short circuit
Communication Interfaces	Modbus RTU, Profibus DP, CANopen, Ethernet/IP
Enclosure Rating	IP21
Ambient Temperature	-10 to +50 °C
Input Voltage	380 to 480 V AC
Cooling Method	Air cooling (natural convection or forced ventilation)
