ABB ACS560 User Manual

200 Parameters
Maximum Combination of selections Speed and Torque: the torque
selector compares the speed controller output (25.01 Torque
reference speed control) and the torque reference (26.74
Torque ref ramp out) and selects the greater of the two.
If speed error becomes positive, the drive follows the speed
controller output until speed error becomes negative again.
This prevents the drive from accelerating uncontrollably if the
load is lost in torque control.
5
19.14 Ext2 control mode Selects the operating mode for external control location EXT2
in vector motor control mode.
For the selections, see parameter 19.12 Ext1 control mode.
Speed
19.16 Local control mode Selects the operating mode for local control in vector motor
control mode.
Speed
Speed Speed control. The torque reference used is 25.01 Torque
reference speed control (output of the speed reference
chain).
0
Torque Torque control. The torque reference used is 26.74 Torque ref
ramp out (output of the torque reference chain).
1
19.17 Local control
disable
Enables/disables local control (startHand and stopOff buttons
on the control panel, and the local controls on the PC tool).
WARNING! Before disabling local control, ensure that
the control panel is not needed for stopping the drive.
No
No Local control enabled. 0
Yes Local control disabled. 1
20
20 Start/stop/direction
Start/stop/direction and run/start/jog enable signal source
selection; positive/negative reference enable signal source
selection.
For information on control locations, see section Local control
vs. external control (page 33).
20.01 Ext1 commands Selects the source of start, stop and direction commands for
external control location 1 (EXT1).
See also parameters 20.02…20.05. See parameter 20.21 for
the determination of the actual direction.
In1 Start; In2
Dir
Not selected No start or stop command sources selected. 0
In1 Start The source of the start and stop commands is selected by
parameter 20.03 Ext1 in1 source. The state transitions of the
source bits are interpreted as follows:
1
No. Name/Value Description Def/FbEq16
State of source 1 (20.03) Command
0
-
> 1 (20.02 = Edge)
1 (20.02 = Level)
Start
0Stop

ABB ACS560 Specifications

General

Frequency	50/60 Hz
Control Method	Scalar control
Protection Features	Overcurrent, overvoltage, undervoltage, short circuit
Communication Interfaces	Modbus RTU, Profibus DP, CANopen, Ethernet/IP
Enclosure Rating	IP21
Ambient Temperature	-10 to +50 °C
Input Voltage	380 to 480 V AC
Cooling Method	Air cooling (natural convection or forced ventilation)
