478 Fieldbus control through a fieldbus adapter
Automatic drive configuration for fieldbus control
The parameters set on module detection are shown in the table below. See also
parameters 07.35 Drive configuration and 07.36 Drive configuration 2.
Notes:
• The optional modules BIO-01 and RIIO-01 are applicable only for frames R0...R2.
• No parameter changes are done for C-series modules. c-series modules are only
supported in frames R3...R8.
Option
10.24 RO1
source
10.27 RO2
source
10.30 RO3
source
20.01 Ext1
commands
20.03 Ext1
in1 source
20.04 Ext1
in2 source
BIO-01 - - - 2 (In1 Start,
In2 Dir)
2 (DI1) 3 (DI2)
RIIO-01 - - - 2 (In1 Start,
In2 Dir)
2 (DI1) 3 (DI2)
FENA-21------
FECA-01------
FPBA-01------
FCAN-01------
FSCA-01------
FEIP-21------
FMBT-21------
FPNO-21------
FEPL-02------
FDNA-01------
FCNA-01------
Option
22.11 Ext1
speed ref1
22.22
Constant
speed sel1
22.23
Constant
speed sel2
BIO-01 1 (AI1
scaled)
4 (DI3) 5 (DI4)
RIIO-01 1 (AI1
scaled)
4 (DI3) 5 (DI4)
FENA-21 - - -
FECA-01 - - -
FPBA-01 - - -
FCAN-01 - - -
FSCA-01 - - -
FEIP-21 - - -
FMBT-21 - - -
FPNO-21 - - -
FEPL-02 - - -
FDNA-01 - - -
FCNA-01 - - -
