Parameter default values for different application macros
The default values listed in the Parameters table on page 161 are applicable for ABB
standard macro (factory macro). The default values may differ for other macros. The
different default values for each application macros are listed in the below table.
Parameter
96.04 Macro select
ABB standard
(1)
ABB standard
(vector) (17)
Torque control
(26)
3-wire
(11)
10.24 RO1 source 2=Ready run 2=Ready run 2=Ready run 2=Ready run
10.27 RO2 source 7=Running 7=Running 7=Running 7=Running
10.30 RO3 source 15 = Fault (-1) 15 = Fault (-1) 15 = Fault (-1) 15 = Fault (-1)
12.20 AI1 scaled at AI1
max
50.000 1500.000 1500.000 50.000
12.30 AI2 scaled at AI2
min
50.000 1500.000 100.000 50.000
13.12 AO1 source 2 = Output
frequency
1 = Motor speed
used
1 = Motor speed
used
2 = Output
frequency
13.18 AO1 source max 50.0 1500.0 1500.0 50.0
19.11 Ext1/Ext2
selection
0 = EXT1 0 = EXT1 5 = DI3 0 = EXT1
19.14 Ext2 control
mode
2 = Speed 2 = Speed 3 = Torque 2 = Speed
20.01 Ext1 commands 2 = In1 Start; In2
Dir
2 = In1 Start; In2 Dir 2 = In1 Start; In2
Dir
2 = In1P Start; In2
Stop; In3 Dir
20.03 Ext1 in1 source 2 = DI1 2 = DI1 2 = DI1 2 = DI1
20.04 Ext1 in2 source 3 = DI2 3 = DI2 3 = DI2 3 = DI2
20.05 Ext1 in3 source
0 = Always off 0 = Always off 0 = Always off 0 = Always off
20.06 Ext2 commands 0 = Not selected 0 = Not selected 1 = In1 Start 1 = In1 Start
20.08 Ext2 in1 source 0 = Always off 0 = Always off 2 = DI1 2 = DI1
20.09 Ext2 in2 source 0 = Always off 0 = Always off 3 = DI2 3 = DI2
20.12 Run enable 1
source
1 = Selected 1 = Selected 7 = DI6 4 = DI3
21.03 Stop mode 1 = Coast 1 = Coast 1 = Coast 1 = Coast
22.11 Ext1 speed ref1 1 = AI1 scaled 1 = AI1 scaled 1 = AI1 scaled 1 = AI1 scaled
22.18 Ext2 speed ref1 0 = Zero 0 = Zero 0 = Zero 0 = Zero
22.21 Constant speed
function
0b0001 0b0001 0b0000
22.22 Constant speed
sel1
4 = DI3 4 = DI3 5 = DI4 5 = DI4
22.23 Constant speed
sel2
5 = DI4 5 = DI4 5 = DI4 6 = DI5
22.24 Constant speed
sel3
0 = Always off 0 = Always off
0 = Always off 0 = Always off
