ABB ACS560 User Manual

Parameters 251
28.92 Frequency ref act 3 Displays the frequency reference after the function applied by
parameter 28.13 Ext1 frequency function (if any), and after
selection (19.11 Ext1/Ext2 selection). See the control chain
diagram on page 486.
This parameter is read-only.
0.00
-500.00…500.00
Hz
Frequency reference after selection. See par.
46.02
28.96 Frequency ref act 7 Displays the frequency reference after application of constant
frequencies, control panel reference, etc. See the control
chain diagram on page 486.
This parameter is read-only.
0.00
-500.00…500.00
Hz
Frequency reference 7. See par.
46.02
28.97 Frequency ref
unlimited
Displays the frequency reference after application of critical
frequencies, but before ramping and limiting. See the control
chain diagram on page 486.
This parameter is read-only.
0.00
-500.00…500.00
Hz
Frequency reference before ramping and limiting. See par.
46.02
30
30 Limits
Drive operation limits.
30.01 Limit word 1 Displays limit word 1.
This parameter is read-only.f
0b0000
0b0000…0b1111 Limit word 1. 1 = 1
No. Name/Value Description Def/FbEq16
Bit Name Description
0 Torq lim 1 = Drive torque is limited by the motor control (undervoltage control,
current control, load angle control or pull-out control), or by the torque
limits defined by parameters.
1…2 Reserved
3 Torq ref max 1 = Torque reference ramp input is being limited by 26.09 Maximum
torque ref, 30.20 Maximum torque 1, 30.26 Power motoring limit, or
30.27 Power generating limit. See the diagram on page 496.
4 Torq ref min 1 = Torque reference ramp input is being limited by 26.08 Minimum
torque ref, 30.19 Minimum torque 1, 30.26 Power motoring limit, or
30.27 Power generating limit. See the diagram on page 496.
5 Tlim max speed 1 = Torque reference is being limited by the rush control because of
maximum speed limit (30.12 Maximum speed)
6 Tlim min speed 1 = Torque reference is being limited by the rush control because of
minimum speed limit (30.11 Minimum speed)
7 Max speed ref lim 1 = Speed reference is being limited by 30.12 Maximum speed
8 Min speed ref lim 1 = Speed reference is being limited by 30.11 Minimum speed
9 Max freq ref lim 1 = Frequency reference is being limited by 30.14 Maximum frequency
10 Min freq ref lim 1 = Frequency reference is being limited by 30.13 Minimum frequency

ABB ACS560 Specifications

General

Frequency	50/60 Hz
Control Method	Scalar control
Protection Features	Overcurrent, overvoltage, undervoltage, short circuit
Communication Interfaces	Modbus RTU, Profibus DP, CANopen, Ethernet/IP
Enclosure Rating	IP21
Ambient Temperature	-10 to +50 °C
Input Voltage	380 to 480 V AC
Cooling Method	Air cooling (natural convection or forced ventilation)
