Parameters 331
On-line Fieldbus communication is on-line, or fieldbus adapter has
been configured not to detect a communication break. For
more information, see the documentation of the fieldbus
adapter.
5
Reset Adapter is performing a hardware reset. 6
51.32 FBA A comm SW
ver
Displays the common program revision of the adapter module
in format axyz, where a = major revision number, xy = minor
revision number, z = correction number or letter.
Example: 190A = revision 1.90A.
0x0000
0x0000...0xffff Common program revision of adapter module. -
51.33 FBA A appl SW ver Displays the application program revision of the adapter
module in format axyz, where a = major revision number, xy =
minor revision number, z = correction number or letter.
Example: 190A = revision 1.90A.
0x0000
0x0000...0xffff Application program version of adapter module. -
52
52 FBA A data in
Selection of data to be transferred from drive to fieldbus
controller through fieldbus adapter A.
Note: 32-bit values require two consecutive parameters.
Whenever a 32-bit value is selected in a data parameter, the
next parameter is automatically reserved.
52.01 FBA A data in1 Parameters 52.01…52.12 select data to be transferred from
the drive to the fieldbus controller through fieldbus adapter A.
None
None None. 0
CW 16bit Control Word (16 bits) 1
Ref1 16bit Reference REF1 (16 bits) 2
Ref2 16bit Reference REF2 (16 bits) 3
SW 16bit Status Word (16 bits) 4
Act1 16bit Actual value ACT1 (16 bits) 5
Act2 16bit Actual value ACT2 (16 bits) 6
CW 32bit Control Word (32 bits) 11
Ref1 32bit Reference REF1 (32 bits) 12
Ref2 32bit Reference REF2 (32 bits) 13
SW 32bit Status Word (32 bits) 14
Act1 32bit Actual value ACT1 (32 bits) 15
Act2 32bit Actual value ACT2 (32 bits) 16
SW2 16bit Status Word 2 (16 bits) 24
No. Name/Value Description Def/FbEq16
