ABB ACS560 User Manual

330 Parameters
51
51 FBA A settings
Fieldbus adapter A configuration.
51.01 FBA A type Displays the type of the connected fieldbus adapter module.
0 = Module is not found or is not properly connected, or is
disabled by parameter 50.01 FBA A enable; 0 = None;
1 = PROFIBUS-DP; 32 = CANopen; 128 = Ethernet;
132 = PROFInet IO; 135 =EtherCAT; 485 = RS-485 comm.
This parameter is read-only.
0
51.02 FBA A Par2 Parameters 51.02…51.26 are adapter module-specific. For
more information, see the documentation of the fieldbus
adapter module. Note that not all of these parameters are
necessarily in use.
0
0…65535 Fieldbus adapter configuration parameter. 1 = 1
…… … …
51.26 FBA A Par26 See parameter 51.02 FBA A Par2.0
0…65535 Fieldbus adapter configuration parameter. 1 = 1
51.27 FBA A par refresh Validates any changed fieldbus adapter module configuration
settings. After refreshing, the value reverts automatically to
Done.
Note: This parameter cannot be changed while the drive is
running.
Done
Done Refreshing done. 0
Configure Refreshing. 1
51.28 FBA A par table ver Displays the parameter table revision of the fieldbus adapter
module mapping file (stored in the memory of the drive).
In format axyz, where ax = major table revision number; yz =
minor table revision number.
This parameter is read-only.
0x0000
0x0000...0xffff Parameter table revision of adapter module. -
51.29 FBA A drive type
code
Displays the drive type code in the fieldbus adapter module
mapping file (stored in the memory of the drive).
This parameter is read-only.
-
0…65535 Drive type code stored in the mapping file. 1 = 1
51.30 FBA A mapping file
ver
Displays the fieldbus adapter module mapping file revision
stored in the memory of the drive in decimal format.
This parameter is read-only.
-
0…65535 Mapping file revision. 1 = 1
51.31 D2FBA A comm
status
Displays the status of the fieldbus adapter module
communication.
Not
configured
Not configured Adapter is not configured. 0
Initializing Adapter is initializing. 1
Time out A timeout has occurred in the communication between the
adapter and the drive.
2
Configuration error Adapter configuration error: mapping file not found in the file
system of the drive, or mapping file upload has failed more
than three times.
3
Off-line Fieldbus communication is off-line. 4
No. Name/Value Description Def/FbEq16
