280 Parameters
Other [bit] Source selection (see Terms and abbreviations on page 162). -
34.112 Boost time duration Defines the time inside which the extra time is deactivated
after extra time activation signal is switched off.
Example: If parameter 34.111 Boost time activation source is
set to DI1 and 34.112 Boost time duration is set to 00 01:30,
the extra time is active for 1 hour and 30 minutes after digital
input DI is deactivated.
00 00:00
00 00:00…07 00:00 Extra time duration. 1 = 1
35
35 Motor thermal
protection
Motor thermal protection settings such as temperature
measurement configuration, load curve definition and motor
fan control configuration.
See also section Motor thermal protection (page 82).
35.01 Motor estimated
temperature
Displays the motor temperature as estimated by the internal
motor thermal protection model (see parameters
35.50…35.55). The unit is selected by parameter 96.16 Unit
selection.
This parameter is read-only.
0
-60…1000 °C or
-76…1832 °F
Estimated motor temperature. 1 = 1°C
35.02 Measured
temperature 1
Displays the temperature received through the source
defined by parameter 35.11 Temperature 1 source. The unit is
selected by parameter 96.16 Unit selection.
This parameter is read-only.
0
-60…5000 °C or
-76…9032 °F,
0...5000 ohm or
[35.12] ohm
Measured temperature 1.
Note: With a PTC sensor, the unit is ohms. If the measured
temperature source selection (35.11) is PTC analog I/O or
PTC AI/DI Voltage divider tree, the motor thermal protection
function converts the analog input signal (35.14) to PTC
resistance value (ohms), and shows it in this parameter. This
is the case even the parameter name and unit refer to motor
temperature (°C or °F). You cannot change the unit to ohm by
the time being (96.16).
1 = 1 unit
35.03 Measured
temperature 2
Displays the temperature received through the source
defined by parameter 35.21 Temperature 2 source. The unit
is selected by parameter 96.16 Unit selection.
This parameter is read-only.
0
-60…5000 °C or
-76…9032 °F,
0...5000 ohm or
[35.22] ohm
Measured temperature 2.
Note: With a PTC sensor, the unit is ohms. If the measured
temperature source selection (35.21) is PTC analog I/O or
PTC AI/DI Voltage divider tree, the motor thermal protection
function converts the analog input signal (35.24) to PTC
resistance value (ohms), and shows it in this parameter. This
is the case even the parameter name and unit refer to motor
temperature (°C or °F). You cannot change the unit to ohm by
the time being (96.16).
1 = 1 unit
35.05 Motor overload
level
Motor overload level as a percentage of the fault limit. 0.0
0.0...300.0 % Motor overload level 1 = 1unit
No. Name/Value Description Def/FbEq16
